QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
6
2.0 - Standard supply and material included in the package
• Windlass
• Reversing contactor box
• Base gasket
• Lever
• Screws for assembly
• Installation and user’s manual, Warranty
• Drilling template
2.1 - Tools required for installation
GP2
• Drill with bit: Ø 9 mm (23/64”) and Ø 11 mm (7/16”)
• Hollow mill Ø 40 mm (1” 9/16)
• Hex wrench: 13 mm
2.2 - Recommended Quick
®
accessories not included
• Controls for control board UP/DOWN
• Push-button panel
• Foot-operated switch
• Hydraulic-magnetic circuit breaker
• Anchor chain counter
• Control system via RRC radio
2 - Supply and equipment
BEFORE USING THE PRODUCT, PLEASE READ THIS USER’S MANUAL CAREFULLY. IF IN DOUBT, PLEASE CONSULT YOUR QUICK® DEALER.
3.0 - Important notes
This manual features Warning and/or Caution symbols that are important for safety.
Please follow the instructions provided.
Warning symbol for dangerous
situations.
Caution symbol to prevent direct or
indirect damage to the product.
Thismanualprovidesboatmanufacturersandnauticalequipmentinstallerswithinstructionsonhowtoassemblethespecied
Quick
®
product and operate it correctly.
3 - Introduction
