Quickie Xplore 2 Owner’s Manual Rev. A 26
N. Adjustments
SEAT - Width Adjustment
Unscrew and remove the 6 to 8 screws located on top of the seat pan and, than
equally adjust the seat width to the desired width and put screws back in place.
Note: The width adjustment must also be made on the rear cross tubes that
hold the back canes and seat laterally.
WARNING:
At all times, the screws holding the seat plates and back
cross tube must be screwed in tight and secured in order to avoid severe
injury and/or damage to the seating system.
SEAT - Depth Adjustment
There is two side lateral frames which will allow for depth adjustment. The short
frame is from 14” to 19” deep and the long frame is from 18” to 22” deep.
To adjust the seat depth, you must loosen the 3 screws from each side plates
and slide them to the desired seat depth.
WARNING:
At all times, the three screws on each side holding the side
plates must be screwed in tight and secured in order to avoid severe
injury and/or damage to the seating system.
BACK - Adjustable Back Angle
Using the series of slotted holes provided on each side plates, increase or
decrease the back angle by loosening the screw from each side plates and
adjust them equally to the desired seat depth.
WARNING:
At all times, the screws on each side holding the back canes
must be screwed in tight and secured in order to avoid severe injury
and/or damage to the seating system.
Adjusting the Center of Gravity
Due to the variety of seat measurements and modular power options available
on various power wheelchairs. Amypower offers many adjustments that allows
the ability to adjust to individual client needs, and properly adjusting the center of
gravity is critical for patient safety and wheelchair performance. To adjust the
center of gravity, unscrew the bolts on each side of the main adaptors and
adjust the system for optimal performance.
WARNING:
At all times, the screws on each side holding the main system
must be screwed in tight and secured in order to avoid severe injury
and/or damage to the seating system.
WARNING:
Before delivering an Amypower product, the dealer must
verify while the user is sitting in the seating system that the center of
gravity and overall stability of the wheelchair is maintained and optimal in
all combinations of tilt, recline or elevation.
