Quicksilver 555PH — General Informaon
12
12V outlet
Trim gauge
Speedometer
Tachometer
Fuel gauge
Helm switch panel
Engine throle shi control
Shut down switch/ lanyard
Engine key
Steering wheel
Helm steering
14. Dash Layout (standard equipment)
USB receptacle
SC1000 Tachometer
SC1000 Speedometer
GPS
Helm selector switch (mechanical)
Stereo
Dash Layout (oponal equipment)
Please note that operator vision from the helm may be obstructed by high trim angles of the cra,
along with other factors such as outboard engine trim angles, hull trim plane angles, loading and load
distribuon, speed & acceleraon, transion from displacement to planing mode, sea condions, rain
and spray, darkness and fog, interior lights, posion of tops and curtains, and persons or movable
gear in the operator’s eld of vision.
