Quicksilver 555PH — Electrical Systems
34
Use only fuses and breakers having the same amperage
rang as the original or as specied. Use of higher
amperage fuses or breakers is a re hazard.
Fuses and breakers
ATO/ATC fuse Thermal breaker ANL fuse Magnec breaker
Helm fuse panel
Dash closeout panel
Helm fuse panel
Blank
Wiper — 10 Amp
Forward bilge — 3 Amp
A bilge — 3 Amp
Navigaon lights — 3 Amp
Horn — 5 Amp
Lighng — 5 Amp
Spare — 10 Amp
Spare — 5 Amp
12V outlet — 10 Amp
Electronics — 5 Amp
Stereo — 10 Amp
Located at the helm, there is a fuse panel accessible via the under dash closeout. To access, simply
open the hatch forward of the helm.
5. Fuses and Breakers
Your boat will either have fuses or breakers protecng the DC electrical system. If you have to replace
a fuse or electrical breaker, replace only with a fuse or breaker of the same rang. The amperage will
be marked on the fuse or breaker, and it is recommended that you carry spare fuses or breakers.
If a fuse or breaker is replaced with one that has a lower amperage, it may not be sucient to carry
the electrical load of the equipment it is connected to and will cause nuisance failures. If a fuse or
breaker is replaced with one that has a higher amperage, it will not provide protecon against an
electrical malfuncon and could create a possible re hazard.
