Quicksilver 555PH — System & Component Overview and Operaon
27
Cabin engine control
Helm selector switch
Exterior helm engine control
Gear & throle mechanism
Main helm
Exterior helm
Exterior Helm
Dual Helm Hydraulic Steering
Steering wheel
Main helm pump
Hydraulic uid lines
Exterior helm pump
Steering cylinder
