28. Sun Lounge (oponal)
If equipped with the reclining a cockpit seat, the L-lounge and the table, the cockpit can be
transformed into a sun lounge. To convert:
• Move the a cockpit seat forward to the middle cockpit posion (a third seat posion
specically added for this opon).
• Rotate the backrest so that it lies at.
• Install the L-lounge ller board. Note: this is similar to the L-lounge bridge seat, but smaller. To
install:
• Set the base into the sloed bracket on the outboard side of the deck.
• Push the inboard side down so that it engages with the rubber stoppers.
Cockpit L-Lounge
Fixed base seat
Bridge seat base
Fixed base seat cushion
Bridge seat cushion
L-lounge seat backrest
Cockpit Sun Lounge
Cockpit table
Filler board
Filler board cushion
Sun lounge cushion
Sun lounge table leg
