Quicksilver 855WE — Electrical Systems
61
DC Helm Fuseblocks
Electronics — 10 Amp
Windshield washer — 5 Amp
Starboard windshield wiper — 10 Amp
Port windshield wiper — 10 Amp
Spot light — 5 Amp
Trim tab breaker — 20 Amp
Navigaon lights breaker — 3 Amp
Forward bilge breaker — 3 Amp
A bilge breaker — 3 Amp
Helm 12V outlet breaker — 10 Amp
Stereo breaker — 10 Amp
Cabin 12V outlets breaker — 10 Amp
Refrigerator breaker — 10 Amp
Water pump breaker — 10 Amp
Horn breaker — 5 Amp
Radar — 10 Amps
Shower sump breaker — 3 Amp
Lighng breaker — 15 Amp
Dealer circuit breaker #1 — 10 Amp
Dealer circuit breaker #2 — 5 Amp
6. AC Electrical System (oponal)
The AC electrical system allows you to use the following 230V appliances while docked and connected
to a shore power system:
1. Baery charger
2. Electrical outlets
3. Mircowave (oponal)
4. Air condioner (oponal)
5. Water heater (oponal)
The shore power receptacle is located on the starboard side of the cockpit, while the AC main panel is
located on under the helm seat. There are four 230V electrical outlets located on the boat. The rst
one is located in the forward berth, the second is located in the upper vanity in the head, the third
one is in the mid berth, while the forth one is located near the interior galley.
A 15m shore power cable with one plug end is also included. Before use, your authorized Quicksilver®
dealer will need to wire the correct plug (for use in your region) on the other end of the shore power
cable.
The 230V / 50Hz wiring consists of three color-coded wires. The brown wire is the “hot” feed, blue
wire is the common, or neutral, and the green wire is ground. The enre system is protected by a
Residual Current Device with Overcurrent Protecon (RCBO), located on the AC panel. From there,
individual line circuits add addional protecon of each appliance in the system.
