Quicksilver 855WE — Electrical Systems
60
Use only fuses and breakers having the same amperage
rang as the original or as specied. Use of higher
amperage fuses or breakers is a re hazard.
1-2-both baery switch
Waste pump switch
Stereo breaker — 10 Amp
Forward bilge breaker — 3 Amp
A bilge breaker — 3 Amp
Carbon monoxide breaker — 10 Amp
Black water pump breaker — 25 Amp
Main breaker #1 — 40 Amp
Main breaker #2 — 30 Amp
Spare
On-o baery switch
Baery Panels
Panel Locaon
breaker is replaced with one that has a higher amperage, it will not provide protecon against an
electrical malfuncon and could create a possible re hazard.
The 855WE has two 10 posion fuse panels located at the helm, behind a service access panel under
the dash. There are also addional breakers located on the baery switch panel.
