Template for Dual and Single
Console Controls
Dual
Control
Centerline forSingle
+t
r
I
3/8”
Dia. for Dual Control
3/8”
(9.53mm) Dia. for Single Control
I
I
I
I
I
Outline of Remote Control Cover for Single Control
I
-
I
1/4”
(.25” or
6.35mm)
Dia. for Single Control
Centerline for Dual Control
--
1/4” Dia. for Dual Control
ACAUTION
Area (located directly under mounting panel) must be free from obstructions
and must allow cables to form a gradual bend when routed toward stern of
boat.
-13-
