Section II - Description
Quincy Compressor7
Gp Pressuregauge Q1/H1 On/off switch with lamp
P1 Hour meter AV Outlet valve
R
Airreceivers(3x10l) Dm Manual drain valve
Da
Automaticdrainoutlet
QOF 5 floor mounted - details
AF Inletairlter AV Outlet valve
Ca
Aircooler E Compressor element
M Motor PS
Pressureswitch
SV Safety valve TSHH Temperatureswitch
CV Checkvalve
QOF with dryer
TheQOFwithdryerconsistsofanQOF,completedwithanintegratedrefrigerantdryer.
Thecontrolpanelcomprisesapressuregauge,anhourmeter,astartbuttonanda
temperaturegaugeindicatingthedewpoint.Thecompressoriscontrolledbyapressure
switch(PS).
Theelectriccomponentsarelocatedinthecubiclebehindthefrontpaneldoor.
Acheckvalve(CV)preventslossofcompressedairwhenthecompressorisstopped.
Atemperatureswitchandasafetyvalve(SV)protectthecompressorelementagainst
overheatingandtoohighpressurerespectively.Thecompressedairiscooledbyanair
cooler (Ca) before it enters the dryer.
Singlephaseunitsareequippedwithaventvalveforeasystarting.
