Section V - Preventive maintenance
Quincy Compressor 23
Period
(note 1)
Running
hours
(note 1)
Operation
Every6
months
- •Manuallyoperatethesafetyvalve.
•Checkforanydamagedwiringorlooseconnections.
•Checkforairleaks.
Every6
months
(note 2)
- Compressorswithintegrateddryer:
•Ifdirty,brushorblowoffthefinnedsurfaceofthedryer’s
condenser.
•Inspectandcleantheelectronicdrain:
•Functioningofthedraincanbecheckedbypushingthe
TESTbuttonofthedrain.
•Cleaningofthedrainltercanbedonebyopeningthe
manual drain valve during a few seconds.
Yearly 2500
•Replacetheairinletfilter(s)(AF)andtheprefiltermatsonthe
coolingairintakeopenings(iffitted)(note2).
•Testthesafetyvalve.
•Havetemperatureprotectionandmotoroverloadtested.
•ChecktensionandconditionoftheV-belt(s).
Every2
years
5000 •ReplacetheV-belt(s).
•Replacecheckvalve.
Every2
years
5000 8barand116psicompressors:
Havetheorbitingscrollbearinggreased(seenote3).
Every2
years
5000 10barand145psicompressors:
•Replacetheelementoutletpipeandtheplasticinsert.See
section Outlet pipe replacement.
(OnlyonQOF2,QOF3andQOF5).
•Cleanfan(FN1-seeFlowdiagram),fanductandelement
cooling fins (see note 2).
•Haveorbitingscrollbearingandpincrankbearingsgreased
(seenote3).
•Replacetipsealsanddustseal(seealsonote4).
Every4
years
10000 8barand116psicompressors:
•Replacetheelementoutletpipeandtheplasticinsert.See
section Outlet pipe replacement.
(OnlyonQOF2,QOF3andQOF5).
•Cleanfan(FN1-seeFlowdiagram),fanductandelement
cooling fins (see note 2).
•Haveorbitingscrollbearingandpincrankbearingsgreased
(seenote3).
•Replacetipsealsanddustseal(seealsonote4).
