Instruction book
9829 3199 74 15
The drains are connected to the side panel of the compressor as shown in the next figure:
Condensate drain connections
Ref. Designation Ref. Designation
1 Automatic drain, aftercooler
2 Automatic drain, intercooler
3 Manual drain, intercooler
4 Manual drain, aftercooler
