GB
FIXED SIDE
SUPPORTS
Height adjustment:
Remove the bolts (A).
Place the supports in the desired position and
remount the bolts.
Width adjustment:
Loosen the bolts (A).
Fasten at the desired position.
GB
QUICK LOCKS
FOR FIXED SIDE
SUPPORTS
Height adjustment:
Remove the bolts (A).
Place the side supports with quick locks in the
desired position and remount the bolts.
Width adjustment:
Pull the quick lock handle up (B).
Lock the handle down when the support is in the
desired position.
UPPER ARM
SUPPORT FOR
THE FIXED SIDE
SUPPORTS
The upper arm supports is developed as an
accessory to seats produced later than De-
cember 2008, i.e. for seats delivered before
this period, you will need a new set of side
supports in order to mount the upper arm
supports.
GB
9
