60 Rabbit 2000 Microprocessor
PB1 (94)
CLKA (serial port A
clocked mode clock,
bidirectional).
CLKA
PB0 (93) CLKB (bidirectional). CLKB
PC7 (51) RXA
PC6 (54) TXA
PC5 (55) RXB
PC4 (56) TXB
PC3 (57) RXC
PC2 (58) TXC
PC1 (59) RXD
PC0 (60) TXD
PD7 (43) ARXA
PD6 (44) ATXA
PD5 (45) ARXB
PD4 (46) ATXB
PD3 (47)
PD2 (48)
PD1 (49)
PD0 (50)
PE7 (21)
/I7—programmable I/O
strobe.
/SCS (slave chip select).
PE6 (22) /I6
PE5 (23) /I5 INT1 (input)
PE4 (24) /I4 INT0 (input)
PE3 (25) /I3
PE2 (27) /I2
PE1 (29) /I1 INT1 (input)
PE0 (30) /I0 INT0 (input)
Table 5-2. Pins With Alternate Functions (continued)
Pin Name Output Function Input Function Other Function
