5.6 DC Characteristics
NOTE: Stresses beyond those listed in Table 5-3 may cause permanent damage. The rat-
ings are stress ratings only, and functional operation of the Rabbit 2000 chip at
these or any other conditions beyond those indicated in this section is not implied.
Exposure to the absolute maximum rating conditions for extended periods may affect
the reliability of the Rabbit 2000 chip.
Table 5-3. Rabbit 2000 Absolute Maximum Ratings
Symbol Parameter Maximum Rating
T
A
Operating Temperature -55°C to +85°C
T
S
Storage Temperature -65°C to +150°C
Maximum Input Voltage
*
* The minimum voltage is -0.6 V DC, which may undershoot to -2.0 V for pulses
that are shorter than 20 ns. The maximum output pin voltage is V
DD
+ 0.75 V DC,
which may overshoot for pulses that are shorter than 20 ns.
-0.6 to (V
DD
+ 0.75) V
V
DD
Maximum Operating Voltage 6.0 V
Max Current Through Input Protection Diodes 5.0 mA
