Page 13
Now remove the plug from the connection socket by gently pressing the locking plug (see image below) while removing
the plug from the socket.
Step 4 of 9
The plugs are locked into the connection sockets by means of a locking clip.
Press the locking clip and pull the plug.
Because the plug is often connected very tightly to the socket, it is helpful,
when pressing the locking clip, to rst push the plug towards the connection
socket before subsequently pulling on it.
In addition, temperature uctuations in the engine bay can result in a type
of “vacuum effect” between the plug and the socket. This can be solved by
lightly “wiggling” the plug.
Please note that there may be different versions of the installed connection
plug. If the plug shown here does not correspond to the plug in your car, you
will fi nd a list of other plugs on page 27 with tips on how they can be removed.
Locking clip
