OPERATION
The Rada V12 Shower Valve is a Thermostatic Shower Control with a Single
Sequential Control Lever for on/off and temperature control.
The Control Lever operates anti-clockwise in the following sequence:
Off On Cold Warm Maximum Preset Temperature
Maximum Preset
Temperature
Off
REVERSED INLET SUPPLIES
Rada V12 Exposed Shower Valve
The Rada V12 Exposed Shower Valve is supplied with inlet connections
Hot - Left, Cold - Right as standard. If the hot and cold water supply pipes have
been reversed during installation the mixer must be removed and rotated 180°.
Note! The Oultet Plug and Outlet Connector must also be removed and retted into
their correct positions.
Upon completion the Control Knob Assembly must be removed, rotated 180° then
retted, refer to section: ‘INSTALLATION - Control Assembly (Built-in Models)’.
Note! it is important that the hot supply is connected to the inlet marked with a red
label.
