rada V12 - Dimensions

9
1145094-W2-D
DIMENSIONS
Rada V12 Exposed Shower Valve
Rada V12 Concealed Shower Valve
111 mm 30 mm
108 mm
Ø 183 mm 60-84 mm 47-71 mm
20 mm
Ø 62 mm
58 mm
Building-in Depth
205 mm
153 mm Centres
109 mm
Ø 56 mm
Ø 62 mm
60 mm
122 mm
35 mm
130 mm
Ø 62 mm
Ø 56 mm
109 mm
122 mm
35 mm
Rada V12 130 Centres Shower Valve
