rada V12 - Introduction; Guarantee; Patents and Design Registration

4
1145094-W2-D
These products have been certied for use in UK Healthcare premises as Type 3
valves under the BUILDCERT TMV3 scheme. For Healthcare installations refer to
the TMV3 Requirements Manual.
The approved designations for Type 3 Valves are as follows:
Key: High Pressure (HP), Low Pressure (LP)
Model Designation
Rada V12 LP-S, HP-S, HP-SE*
* Economy ow rate designation achieved when 6 l/min ow regulator (supplied)
is tted.
Products included in this manual:
Rada V12 Exposed Shower Valve - 1.1651.001
Rada V12 Concealed Shower Valve - 1.1651.002
Rada V12 - 130 Centres Shower Valve - 1.1651.003
INTRODUCTION
The Rada V12 Shower Valve is a Thermostatic Shower Control with a single control
lever for on/off and temperature control. There is no adjustable ow control. A 9 l/
min ow regulator is supplied for high pressure systems to reduce excessive shower
force. For additional water saving a 6 l/min ow regulator is also included.
The Thermostatic Mixer incorporates a wax capsule temperature sensing unit, which
provides an almost immediate response to changes in pressures or temperature of
the incoming water supplies to maintain the selected temperature. An adjustable
maximum temperature limit is provided which limits the temperature to a safe level.
Inlet Filters are tted to protect the thermostatic cartridge.
Patents and Design Registration
Patents:
GB: 2 291 693, 2 340 210, 2 392 223, 2 392 225, 2 421 297, 2 422 886.
Euro: 1 672 257 DE, FR, GB, IT, NL, SE.
USA: 7 240 850, 7 669 776.
Patent Applications:
Euro: 07015846.4
USA: 2006-0124758-A1, 2010-0219255-A1
Guarantee
We guarantee this product against any defect in materials or workmanship for a
period of one year from the date of purchase. For terms and conditions refer to
the back cover.
