7.4. Radar - control of all Georadar operation modes and sounding data receiving in the course
of sounding.
 Connection settings – Control Unit IP address setup. By default it is set to 192.168.0.10.
Control Unit IP address changing is described in Appendix A on p.55.
 Performance – setting of radar performance: single- or double channel.
 Positioning – choosing of method of current coordinates measurement and the total length
of profile (see Section 6 “What to do after installation”).
 Sounds – on/off for sound signals during radar operation.
 Battery warnings – enables or disables low battery charge warnings.
 Tablet controls – enables or disables ability to work with touch panels or computer
mouse.
 Show channel labels – enables or disables ability to show semitransparent channel labels
on the foreground of the signals in dual channel or circle data acquisition mode (Fig.
8.1b.).
 Where to save – choosing a directory where sounding data files will be automatically
recorded.
 When to save – option that switches when the sounding data will be saved – during or
after the acquisition. Program will ask to enter filename and saving location when save
data During acquisition is chosen (this option is preferable to use for long profiles, it will
protect from losing unsaved data in cases like power loss, insufficient RAM space, critical
system errors, etc.).
 Environment options – changes data acquisition menu appearance:
 Color setting - Black & White or Colored buttons in data acquisition menu.
 OFF computer on exit - if this option is ON, anytime when leaving data acquisition
menu you can simultaneously switch off the computer.
 Introduction on start – upon entry, disables or enables colored introduction on the
data acquisition menu screen.
 Introduction on setup – upon data acquisition Setup menu entry, disables or enables
additional dialog window.
 Password on setup - entering of the password to access the acquisition Setup menu.
 Auto launch – turn on/off the automatic Data Receive dialog box run, during the
application startup.
 Start – equivalent of simultaneously pressing Ctrl+A buttons. This option will start data
acquisition window. See Section 9 for more details.
7.5. Processing – digital files processing that were collected earlier in the course of radiolocation
sounding. Processing goal is to extract the useful signals and of noise, interference and
non-informative signals suppression. See Section 11 for more details on this menu options
and the file handling procedure.
7.6. Window – profile windows layout on the display.
 Tile vertical – vertical windows positioning.
 Tile horizontal – horizontal windows positioning.
 Tile smart – windows positioning in consideration of the profiles’ size.
 Cascade – cascaded windows positioning.
7.7. Help – information about the software.
 User’s Manual – open this manual.
 Radar Systems, Inc. web page – open Radar Systems, Inc. homepage.
