P1520 User Guide
Version 1.2 7 04/02/07
Typical RJ12 to DB9M adapter kit (should work for pinpads, scanners, etc)
To connect a peripheral device that requires DB9 to a Radiant P15xx POS terminal via serial cable, order the
following the two items below.
1CBDB9RJ DB9M to RJ12 Adaptor
CB10548 6 ft RJ11 cable
Parallel Port Option
See configuration options
This feature adds an internal parallel port to the connectivity panel and provides data I/O with any parallel
peripheral.
Powered USB (24v) Option
See configuration options
This feature adds a 24 volt, powered USB port into the tilt base of the P1520. Powered USB offers a single
connection receptacle that includes both a standard USB connector and a locking power connector
(USB+power). It accepts either a standard USB device or a 24 volt USB device such as a printer. Similar to
the powered serial ports, the powered USB port eliminates the need for a power brick, thereby reducing another
point of potential failure. This option is only available with the tilt base configuration. For more information
on powered USB, see http://www.poweredusb.org/
Specifications
CPU Intel Celeron M (900Mhz or 1.3Ghz) or Pentium M 1.6GHz
processor (or higher)
Volatile Memory 256MB Std, 2 DIMM slots with up to 2GB DDR SDRAM
supported
Networking Auto-selecting 10Base-T/100Base-T Ethernet using TCP/IP
Primary Display 15” XGA, Active Matrix, dual-bulb, supports auto-stretching
VGA and SVGA resolutions
Speaker Integrated 2 watt X 2 speakers for stereo sound
Touch Screen Native support for 5-wire resistive or capacitive
MPEG Video Decoding Software MPEG decoding supported
Enclosure Polycarbonate/ABS impact resistant, high strength blend,
environmentally sealed
Dimensions (Countertop
envelope through tilt angle)
13.4 to 14.2” L x 15.8 or 16.8” W x 11.5 to 14.2” H,
34.0 to 36.0 cm L x 40.1 or 42.6 cm W x 29.2 to 36.0 cm H
Base Dimension 11.9” L x 10.7” W
30.2 cm L x 27.1 W
Tilt Angle 20° to 100° from vertical
Weight 22.7 lbs., 10.3 kg
Operating Temperature 32°F – 104°F, 0°C – 40°C
Storage Temperature 32°F – 158°F, 0°C – 70°C
Humidity 5% to 85%, non-condensing
Environmental Compliance RoHS, WEEE
EMI Certifications FCC Class A, CE, C-Tick
Safety Certifications UL, CUL, CB Scheme
