Operation
7
BEFORE YOU START
Familiarize yourself with the meter’s
operation before you use it for the first time
by following these steps.
o
1. Rotate the function dial to select one of
the following measurements, then
repeatedly press
SELECT to choose the
function you want.
For example, to measure a diode,
rotate the function dial to
¹
/§/Ω then
press
SELECT twice. § appears.
Measurement
Function (select using SELECT
button)
1. Measures DC voltage.
2. Measures AC voltage.
1. Measures amperage:
•DC40/400mA
• AC 40/400 mA
2. Measures amperage:
•DC4/10A
•AC4/10A
¹
/§/Ω
1. Measures resistance.
2. Checks continuity.
3. Checks diodes.
AA/
C/D
Tests 1.5V C, D, and AA
batteries.
AAA
Tests 1.5V AAA batteries.
Tests 9V batteries.
o
WARNING
o
Always turn off power to
the circuit you are abou
t
to measure before you
connect the test leads to
high voltage.
V
mA/A
9
V
