Radio Systems Millenium-A Analog Console User Manual

Radio Systems Millenium-A Console Page 22
Illustration C-1
Six Channel Audio Board - 5 Pin
IN CH
INPUT 1B
INPUT 1A
IN CH IN CH IN CH IN CH IN CH IN CH IN CH IN CH IN CH IN CH IN CH
1
2
3
4
5
6
7
8
10
8
9
11
12
13
14
15
16
17
Mono/Stereo Select
Channels Sensitivity Select
Loop Thru Bypass
and Mono Select
Loop-Thru
Connector in Circuit
Position A and C strapped
(Pins 1/2 & 4/5 strapped)
Position B and C strapped
(Pins 2/3 & 4/5 strapped)
No pins strapped
Loop-Thru
Connector in Bypass
Loop-Thru Connector Bypassed
and A & B Inputs in Mono
Input or Chassis
Ground Select
5 R+ In
4 R- In
3 Ground
2 L- In
1 L+ In
1 L In
2 L Out
3 Ground
4 R Out
5 R In
1 L Out
2 Ground
3 R Out
Stereo Input (Default)
Input Ground Chassis Ground
(Default)
Mono Input
Jumper Programming
C BA C B A C BA C B A C B A C B A C B A C B A C B A C B A C B A C B A
Post Fader Audio
Output Connectors
(Stereo unbalanced)
Pre Fader Audio
Loop-Thru Connectors
(Stereo unbalanced)
Input
Connectors
(Stereo balanced)
1. Input or Chassis Ground Select
2. Input Connector
3. Mono/Stereo Select
4. Input B Attenuator Dip
5. Input A Attenuator Dip
6. Right Channel Sensitivity Select
7. Left Channel Sensitivity Select
8. Pre-Fader Audio Loop-Thru Bypass Select
9. Pre-Fader Audio Loop-Thru Connector
10. Aux. Power Supply Output
11. Power Supply Input
12. Post Fader Audio Patch Point Connector
13. Mixer Control Cable DIP Socket
14. Mix Buses - Loop Out
15. Audio Ground - Loop Out
16. Audio Ground - Loop In
17. Mix Buses - Loop In
2
9
12
INPUT 2B
INPUT 2A
INPUT 3B
INPUT 3A
INPUT 4B
INPUT 4A
INPUT 5B
INPUT 5A
INPUT 6B
INPUT 6A
SIX CHANNEL INPUT BOARD with 5 Pin CONNECTORS
Note: in mono mode left channel
feeds both left & right.
