Radio Systems Millenium-A Console Page 33
Interface Options and Accessories
5.1 Overview
Several optional interface cards are available for the Millenium-A consoles. These options include:
Enhanced Remote Interface Card - This card connects any input channel’s 15-pin remote connector to provide
relay and opto-isolated channel on/off and start/stop control.
Selector Logic Card - This card adds control logic to the 8 switches located to the right of the monitor section.
Four Source Router Card - This card routes 4 balanced stereo inputs to a single stereo output, which can then
be routed to any standard console input. This option card requires the Selector Logic Card.
DA-Mixer Card - This card can be congured as two stereo 1x2 distribution ampliers (eg. creating two PGM
and AUD outputs), or as one stereo 1x4 distribution amplier. Additionally, this card can be used to cre-
ate special mixes through the use of jumpers (eg. to create two mix-minuses for two single line telephone
hybrids.
Intercom Card - This card enables talkback connection between multiple Millenium consoles and/or standalone
intercom stations. See section 5.2 for detailed operational information.
