Radio Systems Millenium-A Console Page 9
1.5.8 VU Meter Selection (6 Channel Consoles Only)
The six channel console provides only three meters. One meter is dedicated to the TEL output, while the remaining two
are selected by a front panel switch to display either PGM or AUD outputs. The peak LEDs in the meters also follow the
VU meter select switch.
1.5.9 Remote Control
The Millenium Consoles provide extensive remote control using a 15-pin D connector located at each mixing channel.
Each channel has the capability to remote start almost any source. In addition, each channel provides inputs for remote
control of channel on/off and ready lamp illumination.
Sophisticated control interface is also accommodated with the use of the optional interface card (RS Part# 11022). See
Section 2.2.9 and Illustration E-1 for additional information.
1.5.10 Eight Position Switcher
Eight accessory switches are provided on the right-hand side of the console for user control of external equipment or the
optional Four Source Expander or Intercom Accessory boards. These switches and their associated LED indicators can
be wired directly to external equipment using two 15-pin D connectors mounted on the underside of the monitor control
board. Consult Illustration B-3 for more details.
