Millenium Console Specications
Models Available
RS-6A: 6 Channel RS-12A: 12 Channel RS-18A: 18 Channel RS-24A: 24 Channel
Audio Inputs
Type: Differentially balanced instrumentation ampliers with gain set jumpers and selectable input attenuators
Level: Jumper selectable gain settings to accommodate nominal input levels from -60 dBm to +10 dBm. Maxi-
mum input level: +22 dBm
Impedance: 20K ohms or jumper selected
Headroom: 22 dBm at any level
Line Outputs
Type: Active Balanced
Level: Adjustable 0 dBm to +10 dBm, maximum output +22 dBm
Impedance: 100 ohms
Distortion: .008% at nominal operating level, 20 Hz to 20 kHz, PGM, AUD, and Mono outputs
Signal to Noise:
88dB (or better) below +4 dBm output with 0 dBv input level, 20 kHz bandwidth, 600 ohm source impedance
(line to line)
74 dB (or better) below +4 dBm output with - 50 dBv input level, 20 kHz bandwidth, 150 ohm source imped-
ance (mic to line)
Headphone Output
Level: 1 volt RMS nominal, 10 volts RMS maximum into 600 ohm headphone
Distortion: .05% typical, .1% maximum
Impedance: 50 ohms to front panel jack, 330 ohms to prefader (external amp) output
Monitor Sends
Level: 1 volt RMS nominal, 10 volts RMS maximum, 330 ohm unbalanced
Cue Output
2 watts RMS into 8 ohm speaker
Dimensions
6 Channel: 20 3/4" Long x 27" Deep x 9" High
12 Channel: 32 3/4" Long x 27" Deep x 9" High
18 Channel: 44 3/4" Long x 27" Deep x 9" High
24 Channel: 56 3/4" Long x 27" Deep x 9" High
Power Consumption
240 Watts Maximum
