Radiocrafts MPC1 Series User Manual

Page 12 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Command
Details
Comments
ASCII
hex
‘@RC
’
0x40
0x52
0x43
Reset Configuration Memory to factory defaults
This command will reset the configuration memory to the factory
defaults.
Argument
Options
Returns
(none)
(none)
Prompt (>)
At the same time as you run this command you must also assert
the config pin on the module. This is an extra safety to avoid
unintended resets to factory default. It can be disabled by setting
CONFIG_INTERFACE = 1 in the configuration memory.
Note! This command will
also overwrite the serial
number of the module
@’RR
’
0x40
0x52
0x52
Reset
This command will reset the module. It has the same effect as
pulling the reset pin low.
Argument
Options
Returns
(none)
(none)
Prompt (>)
At the same time as you run this command you must also assert
the config pin on the module. This is an extra safety to avoid
unintended resets to factory default. It can be disabled by setting
CONFIG_INTERFACE = 1 in the configuration memory.
‘0’
0x30
Test Mode 0 – List configuration Memory
This command will list all the contents of the non-volatile
configuration memory.
Argument
Options
Returns
(none)
(none)
Configuration
memory
+Prompt (>)
‘1’
0x31
Test mode 1 – TX Carrier
Argument
Options
Returns
(none)
(none)
(none)?
Prompt?
Note! Before using test
mode 1 you need to send
a normal package so that
the TX frequency is
calibrated.
Note!! It is important to
enter Test mode 3 before
exiting the configuration
mode (‘X’) in order to
ensure proper operation
in normal mode.
Note!!! Test mode 4 must
be used between Test
modes 1 and 2.
‘2’
0x32
TX modulated signal, PN9 sequence
Argument
Options
Returns
(none)
(none)
(none)?
Prompt?
