Radiocrafts MPC1 Series User Manual

Page 13 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Command
Details
Comments
ASCII
hex
‘3’
0x33
RX mode, TX off
Argument
Options
Returns
(none)
(none)
(none)?
Prompt?
‘4’
0x34
IDLE
Argument
Options
Returns
(none)
(none)
(none)?
Prompt?
‘7’
0x37
Antenna Tuning
This test mode is an antenna tuning function. It will scan
frequency range +/-2 MHz around the centre frequency.
5 seconds between transmissions and 200 kHz separation
between test frequencies.
Argument
Options
Returns
(none)
(none)
(none)?
Prompt?
RC1701HP-MPC1 only.
The test mode ‘7’ and ‘8’
enable frequency sweep
and pulsed transmissions
and can be used to tune
and optimize an antenna.
See AN025:Tuning the
Antenna with Antenna
Tuning Feature for the
detailed procedure.
Use ‘4’ before exit.
‘8’
0x38
Pulsed transmission
This command will send 100ms packet for every 5 seconds. It is
used to verify antenna.
Argument
Options
Returns
(none)
(none)
(none)?
Prompt?
