RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Room Sensor *)
(Manufacturer specific)
*) Temperature, Battery voltage measured in
the module.
0x7A: Short transport layer header
Do not change
0x44: SND-NR
Do not change
Data and configuration interface, UART Serial Port
UART Baud rate.
BE CAREFUL IF CHANGING AS HOST MAY
LOOSE CONTACT WITH MODULE!
Does not take effect until module is reset.
0x00: MBUS packet with ID and address
Do not change
Configuration interface
As a special protection, the @ commands
require the CONFIG pin to be asserted, but this
can be disabled.
Config pin required for
@ commands
Config pin NOT required for
@ commands
