Radiocrafts MPC1 Series User Manual

Page 18 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Parameter
Addr
(hex)
RC11xx
RC17xxHP
Argument range
Comment
Default/
Factory Setting
PULSE_WEIGHT_1
0x2A
✔
✔
0x00-0x07
Pulse scaling for pulse counter 1.
Liters/volume per pulse
0x00
Special case
The value is incremented for
each transmission (even
without pulse). This can be
used for range test as an
"alive message".
0x01
0.01 Liter or Wh pr pulse
0x02
0.1 Liter or Wh pr pulse
0x03
1 Liter or Wh pr pulse
0x04
10 Liter or Wh pr pulse
0x05
100 Liter or Wh pr pulse
0x06
1000 Liter or Wh pr pulse
0x07
10000 Liter or Wh pr pulse
PULSE_WEIGHT is not used for
DEV = 0x00 or 0x1B (Device type)
0x03
PULSE_WEIGHT_2
0x2B
✔
✔
0x00-0x07
Pulse scaling for pulse counter 2.
See description for PULSE_WEIGHT_1
0x03
BATTERY_THRESHOLD
0x2F
✔
✔
0x01-0xFF
Battery voltage alarm threshold.
𝐵𝐴𝑇𝑇𝐸𝑅𝑌_𝑇𝐻𝑅𝐸𝐴𝑆𝐻𝑂𝐿𝐷 = 128 ∗
𝑉
𝑡ℎ
3
1.25
Default value sets V
th
to 3.0V.
0x66
MPC_WATCHDOG
0x39
✔
✔
0-1
0
0x00
Disabled
1
0x01
Enabled
0x00
