Radiocrafts MPC1 Series User Manual

Page 17 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Parameter
Addr
(hex)
RC11xx
RC17xxHP
Argument range
Comment
Default/
Factory Setting
MPC_DEBOUNCE_1
0x0C
✔
✔
0x00-0x05
Debounce setting for Pulse counter 1
1: 1 ms de-bounce
Debounce time = MPC_DEBOUNCE_1*1ms
Warning: Do not change without careful testing
0x01
MPC_DEBOUNCE_2
0x0D
✔
✔
0x00-0x05
Debounce setting for Pulse counter 2
See description for MPC_DEBOUNCE_1
0x01
PULSE_DIVIDER_1
0x0E
✔
✔
1-2
Divider for Pulse counter 1
1
0x01
One pulse per count
2
0x02
Two pulses per count
0x01
PULSE_DIVIDER_2
0x0F
✔
✔
1-2
Divider for Pulse counter 2
See description for PULSE_DIVIDER_1
0x01
MPC_FLOW_1
0x17
✔
✔
0-18
Flow for pulse counter 1
0: Disable
1-18: Flow over N hours
If > 0 a data point for flow will be added. The
value set must correspond to the transmission
interval TX_INTERVAL_H/L in hours
0x00
MPC_FLOW_2
0x18
✔
✔
0-18
Flow for pulse counter 2
See description for MPC_FLOW_1
0x00
COUNTER_1_INIT
0x21-
0x24
✔
✔
32bit initial coutner value for pulse counter 1.
Start value after reset.
Addr 0x21: MSB
Addr 0x24: LSB
Note! COUNTER_1_INIT sets the internal
COUNTER_1_VALUE. The reported counter
status is always COUNTER_1_VALUE /
PULSE_DIVIDER_1.
0x00000000
COUNTER_2_INIT
0x25-
0x28
✔
✔
32bit initial coutner value for pulse counter 2.
Start value after reset.
Addr 0x25: MSB
Addr 0x28: LSB
Note! COUNTER_2_INIT sets the internal
COUNTER_2_VALUE. The reported counter
status is always COUNTER_2_VALUE /
PULSE_DIVIDER_2.
0x00000000
