Radleys Reactor-Ready Lab Reactor - Jacketed Glass Reaction and Filter Vessels

49
Filter Plate Benchtop Support
Step 1
The Filter Plate Benchtop Support comes
assembled ready for use.
Ensure that the M6 screw on the bottom of the
Benchtop Support is screwed tightly.
Step 2
Clamp the Filter Plate Benchtop Support to a
suitable retort stand using the Stainless-Steel
rod.
Adjust the height and position of the Filter Plate
Benchtop Support as required.
Step 3
Place the retort stand with the Filter Plate
Benchtop Support on a flat and stable surface
The Filter Plate Benchtop Support is now ready
for use with the Filter Plate Assembly.
