Step 1
Ensure that the Filter Plate Assembly is securely
clamped to the Filter Vessel as described in
Sections 6.1.3 and 6.2.1.
Step 2
Place both halves of the Filter Cake Catcher
around the Filter Plate, lining up the bottom flaps
and the top clips. Push them together until an
audible click is heard. The Filter Cake Catcher is
now secure.
Step 3
After filtration, the Filter Plate can then be
removed from the vessel. The Filter Cake Catcher
will capture any solids from the filtration.
Step 4
To detach the Filter Cake Catcher from the Filter
Plate Assembly, ensure that the Filter Assembly is
secured and press on the tabs next to the top
clips to release the two halves.
