Means of operation:
− Press key to print the header (PRINTOUT 1)
− Carry out a measuring series (set all options of the GLP menu to NO), and accept
each measurement result by pressing <ENTER> key
− On completing a measuring series press F key to print a statistics from the series
− In order to continue the measuring series accept it by pressing <ENTER> key or
− Press key to print a footer (PRINTOUT 2).
For the purpose of increasing the speed of statistical calculations it is possible to enable
the option of automatic erasing statistics. The option is set in parameter: P5 (RS 232) 12
<Erase statistics>.
0 - no (the statistics are not erased. Erasing is carried out by entering mode settings and
selecting option <ERASE>
1 – on header (the statistics is erased directly on pressing key which precedes
printout of a header)
2 – on footer (the statistics is erased directly on pressing key after printing a footer).
