TABLE 2
Variables independent on enabled working mode
Variable
Number of characters
needed for a variable
Variable description
%% 1 Printout of a single character “%”
%N 16 or 18 * Current net mass in basic measuring unit
%d 10 Current date
%t 8 (for 24-hour version) Current time
%i 8 Balance factory no.
%R 8 Software no.
%P 8 Project no.
%U 8 User no.
%F X ** Name of an active working mode
%C 25
Date and time of last completed adjustment
process
%K X ** Type of last completed adjustment process
%I 16 or 18 *
Deviation in last completed adjustment
process
%1 6 Code 1
%2 6 Code 2
%3 6 Code 3
%4 6 Code 4
%5 6 Code 5
%6 6 Code 6
%V 16 or 18 *
Mass in current measuring unit. Variable
value is combined with an active working
mode, e.g. number of counted parts in
Parts Counting mode or deviation from
reference mass in % in the Percent Setup
* depending on settings of a digit marker and printout parameter: to a printer / PC
** depending on the length of a name
