ESP-ME3 Controller
14
EN
Special Features
a
Turn the dial to the desired position indicated
below for each Special Feature.
b
Press and hold and at the same time.
Set Interstation Delay
by Program
A station delay (from 1
second to 9 hours) ensures
that a valve has completely
closed before the next one
opens. Press Program Select
to set delay for different
programs.
Set Rain Sensor by
Station
Tells a station to obey or
ignore a rain sensor.
Save
Programming
Restore
Programming
Set Master Valve
by Station
Allows a station to be
controlled by a master
valve or pump start relay.
Set to Odd or Even
Watering Days
Options
Reset Button
If the controller is not working properly, you can try
pressing RESET.
Insert a small tool such as a paper clip, into the
access hole and press until the controller is reset.
All previously programmed watering schedules will
remain stored in memory.
RESET
Remote Accessories
A 5 pin accessory port is available for Rain Bird
approved external devices, including:
LNK
TM
WiFi Module
LIMR Receiver Quick Connect harness
PORT
Set Flow Sensor by Station
Turns a flow sensor on or
off by station
Reset to Factory Defaults
All programmed schedules
will be erased.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Rain Bird ESP-7ME3 and is the answer not in the manual?

Rain Bird ESP-7ME3 Specifications

General IconGeneral
Number of Zones/Stations7
EnclosureIndoor/Outdoor
Programs4
Watering Start TimesUp to 4 per program
Water BudgetYes
Seasonal AdjustYes
Rain Sensor CompatibilityYes
Cycle and SoakYes
Rain DelayYes
Display TypeLCD
Wi-Fi CompatibleNo
Enclosure MaterialPlastic
Power SourceAC
Voltage24V
