Rain Bird ESP-LXIVM - Troubleshooting Procedures; 2-Wire Mapping Process

11 ESP-LXIVM Controller Troubleshooting Guide
Table of
Contents
2-Wire Mapping
2-Wire Mapping “maps” or records information on the wire-path of any
connected IVM devices. A total of 4 wire paths are available in a LX-IVM
Controller.

NOTE: While this information is helpful for diagnostics, not doing
2-wire mapping WILL NOT affect irrigation functions. But if 2-wire
mapping is NOT done, it will raise an alarm at the controller.
To initiate 2-wire mapping, follow the steps below:
Turn the Dial to 2-Wire Settings
1. At the Advanced Station Settings screen, press the Down Arrow
key to select 2-Wire Mapping, then press Next.
2. At the 2-Wire Device Mapping screen, press the + and – keys to
set the desired hour (from 0 to 23), then press the Right Arrow
key.
Cycle & Soak
Next
Inter-Station Delay
SimulStations
2-Wire Mapping
Station Sequencing
Advanced Station Settings 2-Wire Device Mapping
HH:MM
Start Device Mapping In
Next
00 00:
3. Press the + and – keys to set the desired minute (from 1 to 59),
then press Next.
4. At the confirmation screen, press Start to begin Device
Mapping.

NOTE: All irrigation is disrupted during the mapping process.
2-Wire Device Mapping
Start Device Mapping In
Next
HH:MM
01
05:
Start
and could take several
interrupt all irrigation
Device Mapping will
Attention
minutes
