Rain Bird ESP-MC - Page 39

Appendix B, continued
35
Central Computer
Phone
Point-to-point
Radio
Link
Trunk
Radio
Cellular
Telephone
Satellite
Controller
Decoder
Satellite
Controller
Valve
Sensor
Hardwire/
Short-haul
Modem
Two-wire Path (TW) MAXILink Radio (LINK/R)
Weather Station
Sensor
Switch
or
CCU
at site
CCU
at site
Valve Valve
Valve
1. Central
Computer
2. Computer
Data Path
Options
3. CCU
4. Satellite Data
Path Options
5. Field Devices
6. Stations
7. Weather
Station
Phone (PH) Version Radio/Direct Version
