Rain Bird ESP-MC - Page 41

Appendix B, continued
37
Central Computer
Phone
Point-to-point
Radio
Link
Trunk
Radio
Cellular
Telephone
Hardwire/
Short-haul
Modem
Weather Station
Switch
or
ESP-SITE-Satellite
Controller
ESP-SITE-Satellite
Controller
Fiber Optic
Cable
Valve Valve
Sensor
Valve Valve
Sensor
1. Central Computer
2. Computer Data
Path Options
3. ESP-SITE-Satellite
Controller
4. Stations
5. Weather Station
Phone (PH) Version Radio/Direct Version
