Rain Bird ESP-Me Series User Manual

Display Legend
This manual uses USA domestic icons for illustration purposes. The following table lists the differences between the domestic
and international display screen symbols. Choose your voltage below to determine the LCD symbols for your controller.
Domestic vs. International Display Symbols
120V & 240V 230V English
OFF
Off
NEXT
Next Watering Day
MO
1
Monday
TU
2
Tuesday
WE
3
Wednesday
TH
4
Thursday
FR
5
Friday
SA
6
Saturday
SU
7
Sunday
DAY
DD
Day
MONTH
MM
Month
YEAR
YY
Year
HOUR
HH
Hour
MINUTE MM
Minute
1
,
3
,
5
...
ODD
1
,
3
,
5
...
29
1, 3, 5
Odd Days
2 , 4 , 6 ...
EVEN
2,4,6...30
2, 4, 6
Even Days
STATION
Station
START TIME
Start Time
RUN TIME
Run Time
REMAINING RUN TIME
Remaining Run Time
SEASONAL ADJUST %
Seasonal Adjust
DELAY
Rain Delay
MANUAL
Manual Watering
TEST Test All Stations
DELAY
DELAY
Delay Between Valves
2
ESP-Me User Manual
Introduction

Rain Bird ESP-Me Series Specifications

General

Display	LCD
Programming Schedules	Up to 4 independent programs
Weather Sensor Input	Yes
Controller Type	Modular
Seasonal Adjust	5% to 200%
Electrical Input	120 VAC
Electrical Output	24 VAC
Surge Protection	Yes
Watering Start Times	6 per program
Cycle and Soak	Yes
Rain Delay	Yes
Power Supply	External transformer
Housing Material	UV-resistant plastic
WiFi Capability	Optional (with LNK WiFi Module)
Watering Schedule	Custom days, odd/even days, cyclic
Remote Compatibility	Yes, with remote
Stations	4, 6, 12 (depending on model)
Start Times	6 start times per program
