Rainin Pipet-Lite - Replacement Parts Identification

Replacement Parts (see pages 12-13)
Legend for Pipet-Lite 2 µL to 2000 µL
A - Plunger Button B- Shaft Coupling C - Shaft*
D - Tip Ejector* E - Piston Assembly F - Seal
G - O-ring H - Stroke Spring J - Seal Retainer
L- Series:
L-2 L-10 L-20 L-100 L-200 L-1000 L-2000
A 6202-055 6202-056 6202-057 6202-058 6202-059 6202-060 6202-192
B 6202-062 6202-062 6202-062 6202-062 6202-062 6202-062 n/a
C 6202-063 6202-064 6202-065 6202-066 6202-229 6202-230 6202-214
D 6202-071 6202-071 6202-071 6202-073 6202-231 6202-232 6200-168
E 6202-076 6202-077 6202-078 6202-079 6202-080 6202-081 6202-082
F 6200-131 6200-138 6200-143 6200-150 6200-154 6200-161 6200-166
G 6200-132 6200-139 6200-170 6200-151 6200-155 6200-162 6200-167
H 6202-083 6202-083 6202-083 6202-084 6202-084 n/a n/a
J 6200-196 6200-196 6200-198 6200-201 6200-200 n/a n/a
SL- Series:
SL-2 SL-10 SL-20 SL-100 SL-200 SL-1000 SL-2000
A
6202-109 6202-110 6202-111 6202-112 6202-113 6202-114 6202-115
B 6202-062 6202-062 6202-062 6202-062 6202-062 6202-062 n/a
C 6200-134 6200-140 6200-145 6200-147 6200-382 6200-383 6200-169
D 6200-133 6200-133 6200-144 6200-148 6200-231 6200-232 6200-168
E 6202-183 6202-184 6202-185 6202-079 6202-080 6202-081 6202-082
F 6200-131 6200-138 6200-143 6200-150 6200-154 6200-161 6200-166
G 6200-132 6200-139 6200-170 6200-151 6200-155 6200-162 6200-167
H 6202-083 6202-083 6202-083 6202-084 6202-084 n/a n/a
J 6200-196 6200-196 6200-198 6200-201 6200-200 n/a n/a
*These parts are autoclavable (C - shaft, D - tip ejector arm)
Legend for Pipet-Lite 5000 µL , 10 mL and 20 mL
A - Plunger Button C- Tip Ejector* D - Piston Assembly
E - Piston O-ring F - Cylinder G - Cylinder O-ring H - Shaft*
11
L- Series: SL- Series:
L-5000 L-10ML L-20ML SL-5000 SL-10ML
A 6202-193 6202-194 6202-297 6202-217 6202-218
C 6200-373 6200-374 6202-298 6200-373 6200-374
D 6202-215 6202-216 6202-296 6202-215 6202-216
E 6200-363 6200-369 6202-299 6200-363 6200-369
F 6200-365 6200-371 6202-301 6200-365 6200-371
G 6200-364 6200-370 6202-300 6200-364 6200-370
H 6202-222 6202-223 6202-302 6200-362 6200-368
*These parts are autoclavable (C - tip ejector arm, H - shaft)
Common parts for 5000 µL, 10 mL, and 20 mL:
Tube of grease: 6100-555
Filters for 5000 µL and 10 mL: 6190-164 (pack of 100)
6190-165 (pack of 1000)
for 20 mL: 6190-221 (pack of 100)
6190-222 (pack of 500)
