Rainin Pipet-Lite - Introduction; Figure 1 Pipet-Lite Pipette

1
Figure 1 Pipet-Lite 200 µL
Plunger button /
volume adjustment
Tip ejector
button
Stainless steel tip
ejector arm
Volume lock
Digital
volume
indicator
Body:
high-impact,
low thermal
conductivity
polymer
Shaft
Disposable tip
Introduction
Pipet-Lite is an air-displacement pipette which incorporates
major ergonomic improvements to reduce the risk of repeti-
tive strain injury and pain – low force seals and lower spring
forces contribute to a lighter feel. A magnet is used to help
sense and hold the piston in the zero position, which reduces
static force on the operator’s hand.
In the models with LTS
™
shafts, the patented LiteTouch
™
Tip
Ejection System reduces total pipetting forces by up to 70%.
Tip ejector arm
