© 2005 SANDVIK TAMROCK CORP.Page 44 - MAINTENANCE
Removal of tool S 83 STD
7. Remove retaining pin.
8. Remove tool retaining pins.
9. Remove tool. Use lifting device if necessary. See “Tool specifications” on page
56.
Note: If hammer is still on carrier, it may be easier to stick the tool in the ground
and lift the hammer off the tool. Make sure that the tool can not fall.
