RAMMER S 83 STD - Removal of Lower Tool Bushing

MAINTENANCE - Page 47© 2005 SANDVIK TAMROCK CORP.
Lower tool bushingS 83 STD
REMOVAL OF LOWER TOOL BUSHING
Do not throw used hammer tool bushing away at job site. Used tool bushings
can be recycled by delivering them to an authorized scrap metal collection fa-
cility.
1. Remove tool.
2. Remove split pin and retaining pin.
3. Remove lower tool bushing.
