TRAKFAST REPAIR MANUAL
35
Rev. 09/07
Slide off Cage and Spring.
(part #7405144 only comes as an assembly)
(Spring, part #401488)
Lift out Mid-check Retaining Ring (part #401322).
Remove with Snap Ring Pliers (part #401333).
Remove 2 Wave Washers and 1 Seal Washer (part #7405056).
Housing Assembly (cont’d)
TOOL DISASSEMBLY
Remove Bumper (part #7505109) using Bumper Removal Tool.
To Next Page
