Preparing for use
R&S
®
NRP Series
16Getting Started 1419.0170.02 ─ 16
2. Remove the cable.
3.7 Connecting to a controlling host
As a controlling host, you can use:
Computer
Base unit
For operating the power sensor, you can choose from various possibilities. For
details, see Chapter 5, "Operating concepts", on page 32.
3.7.1 Computer
If the controlling host is a computer, you can operate the power sensor in several
ways. For details, see Chapter 5, "Operating concepts", on page 32.
Establish the connection using:
Host interface
See Chapter 3.7.1.1, "Simple USB connection", on page 16.
See Chapter 3.7.1.2, "R&S NRPZ5 sensor hub setup", on page 17.
LAN interface, if the power sensor is a LAN power sensor
See Chapter 3.7.3, "Using a LAN connection", on page 20.
3.7.1.1 Simple USB connection
All R&S NRP power sensors can be connected to the USB interface of a com-
puter.
Required equipment
R&S NRP power sensor
R&S NRPZKU cable
Connecting to a controlling host
