Power sensor tour
R&S
®
NRP Series
31Getting Started 1419.0170.02 ─ 16
Further information:
For details on configuration, see the user manual.
4.5 LAN PoE interface
Available only for LAN power sensors.
An Ethernet RJ45 connector is used to connect the LAN connector to a local area
network (LAN).
Supply the electrical power over the LAN PoE interface. See Chapter 3.5,
"Powering the power sensor", on page 14.
LAN reset button
The LAN reset button is used for resetting the Ethernet connection parameters of
the power sensor to their default values.
Power over Ethernet status LED
The power status LED shows whether the sensor is correctly powered over PoE
or not.
Color State
Green The sensor is powered over PoE. You can operate it using the Ethernet interface.
No light No PoE power is present.
Network status LED
The network status LED shows whether the LAN connection to the network is
established properly or not.
Color State
Green The power sensor is correctly connected to the network.
It has been assigned a valid IP address, either manually or via DHCP.
Red The power sensor is not connected to the network correctly.
Either the connection is erroneous or the sensor has not been assigned a valid
IP address yet.
LAN PoE interface
