Starting a measurement
For a detailed description of how to measure in this setup, refer to the operating
manual of the R&S NRPV.
1. Start the R&S NRPV.
2. Execute zeroing.
Note: Turn off all measurement signals before zeroing. An active measure-
ment signal during zeroing causes an error.
3. Switch on the test signal of the signal source.
4. Start a measurement.
5.5 R&S Power Viewer
The R&S Power Viewer is software that simplifies many measurement tasks. It is
provided on your documentation CD-ROM and on the Rohde & Schwarz website
as a separate standalone installation package.
Required equipment
●
R&S NRP power sensor
●
R&S NRP‑ZKU cable or an R&S NRP‑Z5 sensor hub and an R&S NRP‑ZK6
cable to connect the sensor to the computer
●
Computer with installed:
– R&S NRP Toolkit V 4.20 or higher
– R&S Power Viewer version 9.2 or higher (refer to the operating manual of
the R&S Power Viewer for a description of the installation process)
If you want to use an android device like a tablet or a smartphone, use the
R&S Power Viewer Mobile. For details, see Chapter 5.6, "R&S Power
Viewer Mobile", on page 41.
