RAD16z
The RAD16 is a popular device for adding flexible I/O capability to Halogen systems. The new RAD16z adds fur-
ther flexibility with the following improvements:
l
Two universal Mic/Line/Line-Plus inputs
l
Two logic inputs and two logic outputs
l
Improved audio performance
l
500-volt galvanic isolation from RAD port
l
Same plenum-rated chassis as RAD16
How To Use
The RAD16z covers applications possible with the original RAD16 with significant improvements qualifying it
for even more applications, while still having the same plenum rating as RAD16. Most notably, it covers appli-
cations where galvanic isolation, logic I/O and universal Mic/Line/Line-Plus inputs are needed.
The addition of Logic I/O allows a RAD16z to support operations like push-to-talk microphones, preset recall,
lighting and projector screen control. The RAD Port of the device features 500 volt galvanic isolation, a useful
CHAPTER 2: Hardware Component Details
29
