MP2014 MANUAL
Class Compliant USB Ports
The USB ports are 100% class compliant, connecting to Mac OS X without the need for an additional driver. A high-
performance ASIO driver runs most Windows DAW and DJ software. MIDI end points are class compliant with both OS X
and Windows devices. Mac and Windows Control Panel installers with additional mixer settings are included on the CD-
ROM with the MP2014, and current versions available from the Downloads link in the MP2014 page at dj.rane.com.
ASIO (Windows)
A low-latency ASIO driver interfaces with most DJ and DAW audio software applications on Windows operating systems.
Multi-client ASIO allows different audio software applications to simultaneously stream audio to and from the MP2014.
If the same playback channel is selected in more than one application, the driver mixes the audio from the applications
before streaming it to the device. ASIO driver and Rane Control Panel system requires Windows 7-SP1, 8.1, or 10. The driver
Control Panel may be launched from the Windows Control Panel. Select Start > Control Panel > Rane Products.
Core Audio (Macintosh)
No driver installation is required. Connect the MP2014 to a Mac running OSX, and the MP2014 inputs and outputs become
available in your audio program. Install the Rane control panel to provide additional setting as described below.
Control Panel
NOTE: Settings are saved in the mixer. The control panel for Windows or Macintosh is updated with the mixer’s settings.
Therefore, when you connect to a different MP2014 Mixer, it's saved settings override your previous Control Panel settings.
NOTE: The Rane Control Panel and Firmware may be updated with new features over time. To get the most from your
MP2014, occasionally check the Downloads link in the MP2014 page at dj.rane.com.
Settings
The MP2014 allows you to save and export settings. You can load your preferences when using a different MP2014 than
your own, or putting things back after another DJ has used your mixer.
Once you have set control panel preferences, click Export to write these to a computer le. Click Import to load a .rms
settings le. The control panel shows the current settings le loaded in the mixer. If any changes are made since the last
import, [Modied] will appear after the lename along with a Save button, offering to save your changes as the new default.
Firmware
The MP2014 Firmware Version currently installed in the MP2014 is shown. The Downloads link on the MP2014 page at
dj.rane.com is the place to check if there is a control panel / rmware update. After downloading and installing, if the
MP2014 rmware installed on your computer is newer than the rmware in your MP2014, an Update Firmware button is
enabled. Pressing the button updates the MP2014 rmware to the new version.
General Tab
Main Out can be set to Stereo or Mono. The Booth and
Session Outputs are always in stereo.
Headphone Tone slider adjusts the tone going to the
headphones using spectral tilt lters.
• Increasing Treble reduces lows by the same amount.
• Increasing Bass reduces highs by the same amount.
Mic Clean Feed when selected, the microphone signal
is only sent to the Main Out and is not present in the USB
Main Record, Booth Out or Session Out. This allows you to
record your set without any house announcements. Default
is Off.
